HUD-E808

Salt Spray Test Chamber is mainly suitable for the surface treatment of various materials, including coatings, electroplating, organic and inorganic coatings, extreme treatments, anti-rust oils and other anti-corrosion treatments to test the corrosion resistance of products.


Features

  • FEATURES

    1.Durable 8 mm PVC construction, anti-corrosion and easy to clean.

    2.Reservoirs with mixing system on stand.

    3.Separate heating system apart from salt testing chamber to ensure accurate result and protect circuit.

    4.Exposure zone lined with corrosion-resistant PVC sheets.

    5.Clear cover allows viewing of test conditions.

    6.Peaked cover prevents dripping of condensation onto samples.

    7.Water seal and water level protection system.

    8.Heated humidifying tower with air relief valve, adjustable tower tip to orient salt fog.

    9.Automatic DI water fills to humidifying tower.

    10.Digital temperature control.

    11.Integral over-protection on heaters.

    12.Low water cut-off protection on humidifying tower.

Specifications

Model

HUD-E808-60

HUD-E808-90

HUD-E808-120

HUD-E808-160

HUD-E808-200

Inner Chamber Size   (L×W×H) cm

60×40×45

90×60×50

120×100×50

160×100×50

200×120×60

Outside Chamber Size  (L×W×H)cm

107×60×118

141×88×128

190×130×140

230×130×140

270×150×150

Equipment Material

Both inside & outside shell adopt imported P.V.C rigid plastic board, and tank cover uses imported transparent P.V.C. rigid plastic board

Temperature Range

35℃~55

Temperature Fluctuations

 ±0.5

Temperature Uniformity

2.0

Temperature Precision

±1

Test Chamber Temperature

Salt Spray Method (NSS ACSS)35±1℃ Corrosion-resistant Testing Method(CASS) 50±1℃

Saturated air Barrel Temperature

Salt Spray Method (NSS ACSS)47±1℃ Corrosion-resistant Testing Method(CASS) 63±1℃

Brine Temperature

35℃±1℃

Spray Quantity

1.0~2.0 ml / 80cm2 / hr (Collect at least 16 hours and take the average)

PH

Salt Spray Method (NSS ACSS6.5~7.2) Corrosion-resistant Testing Method (CASS)3.0~3.2

Lab Volume

108L

270L

600L

800L

1440L

Brine Tank Capacity

15L

25L

40L

40L

40L

Power

1∮AC220V,10A

1∮AC220V,15A

AC 1∮,220V,30A

Multiple Safety Protection Devices

Current discharge protection, over pressure protection, over temperature protection, over load fuse protection

Accessories

Testing Salt/ Measuring tank/ Nozzle Equipment  each 1 set
