Specifications
| Model | HUD-E710-5 |
| Internal dimension | Diameter 600 * height 1000mm |
External dimension | Diameter 820 * height 1200mm |
Chamber material | SUS#304, thickness 2mm |
Water depth | Simulate 50m depth by air compressor |
Water pressure | Ambient to 0.5MPa, pressure gauge accuracy 0.25 degree |
Timer | 0 ~ 99min, 99sec |
Sample lift device | Portable stainless steel basket |
Water level display | Water pipe with scale |
Protection device | Pressure protection and anti-explosive device, water drain and pressure release device |
Safety protection | Power overload protection, short circuit protection, grounding protection, alarm display |
Power supply source | three-phase, 380V±10%, 50/60Hz (can be appointed) |
Features
DETAILS
SUS304 # stainless steel plate and high-precision overall sub-arc welding, outer mirror polishing, inner layer rough throw, beautiful appearance, convenient cleaning and durability.
special silicone sealing ring (elasticity, never aging, the tube used for ten years).
the electronic control components are all imported LG, Panasonic, Omron, Anliang and other brands.
time control function, set the time 0-999 minutes, automatically stop when the set time is reached, and automatically drain the air inside the tank, the tester can open the can lid to take out the test sample.
bottom of the tank body has a water inlet valve and a drain valve, and a 5 meter water hose is provided.
the base is equipped with 4 activities with brake casters, easy to move.
IP series
| IP SERIES | ||
IPX-1 | Protected against falling water | Equivalent to 3-5mm rainfall per minute for a duration of 10 minutes. Unit is placed in its normal operating position. |
IPX-2 | Protected against falling water | when tilted up to 15 degrees - Same as IPX-1 but unit is tested in 4 fixed positions - tilted 15 degrees in each direction from normal operating position. |
IPX-3 | Protected against spraying water | Water spraying up to 60 degrees from vertical at 10 liters/min at a pressure of 80-100kN/m2 for 5 min. |
IPX-4 | Protected against splashing water | Same as IPX-3 but water is sprayed at all angles. |
IPX-5 | Protected against water jets | Water projected at all angles through a 6.3mm nozzle at a flow rate of 12.5 liters/min at a pressure of 30kN/m2 for 3 minutes from a distance of 3 meters. |
IPX-6 | Protected against heavy seas | Water projected at all angles through a 12.5mm nozzle at a flow rate of 100 liters/min at a pressure of 100kN/m2 for 3 minutes from a distance of 3 meters. |
IPX-7 | Protected against water immersion | Immersion for 30 minutes at a depth of 1 meter. |
IPX-8 | Protected against water submersion | The equipment is suitable for continual submersion in water under conditions which are identified by the manufacturer. |
IPX-9 | Protection against high-pressure water splashes | The water pressure should be 8–10 MPa (80–100 bar) at distance of 0.10–0.15 meters.The water temperature should be 80 °C. |
